EAE A1-8 Compact Acoustic Amplifier with Lithium Battery

EAE A1-8 Compact Acoustic Amplifier with Lithium Battery

A1-8 Compact Acoustic Amplifier with mixer, monitor controls, digital effects and Lithium Battery

While keeping similar input/output features as the A1-4 MKII, the A1-8 Compact Acoustic Amplifier also has one High Z input and GND lift for the XLR output, packed into the same size cabinet as the D6-8 PRO.  The EAE A1-8’s superb functionality and portability provides unparalleled versatility.  A1-8 Compact Acoustic Amplifier featured Mix, Digital Effects, and Monitor sections seamlessly combine to elevate your performance.  Powered by a LifePO4 Lithium Rechargeable Battery, playtime on the A1-8 is 4-6 hours..

For more channels or more tone control, consider adding one of our mixers, the A1-8 is equipped  with a +9VDC (500mA) output to power our StompMix 4 or GigMix 4-1 compact digital mixers.

FREQUENT QUESTIONS:

1. NO sound from Amp with Chan 1 or 2/3 Inputs but Sound with Aux Input.

Answer – Check the EFX MIX knob position and make sure it is not Full Clockwise (All WET), set Mix Knob to 12 O’clock and re-check.

PROTECTION CIRCUITS AND LIFEPO4 BATTERY SAFETY

The A1-8 utilizes the same Lithium Iron Phosphate (LifePO4) batteries and protection/charging circuits as A6-55 since 2018.  LifePO4 batteries are “NOT” the same type as Lithium Ion (Li+) or Lithium Polymer Batteries (LiPO or Li-Poly).  We selected Lithium Iron Phosphate (LifePO 4) type of batteries for it’s advantages in safety properties and long service life. LifePO4 is thermally and chemically stable, reliable without the possibility of lithium fires. LifePO4 batteries have long service life, with a shelf life that far exceeds the service life of many other batteries.  Not only we enclosed the Batteries in a metal cage, we added many Battery Protection circuits – Over Voltage protection, Thermal Shutdown, Over Charge protection, Over Drain protection. The LifePO4 batteries are used in our products are UL safety approved and MSDS certified.

A1-8 Battery Powered Acoustic Amplifier features

  • 1 High Z input,
  • GNG lift for XLR outputs
  • 1 Class-A Mic and 2 Line inputs
  • +48V Phantom Power
  • 16 selectable Digital Effects
  • Auxiliary Input
  • 8” woofer  & 1” inch tweeter
  • Monitor section; 3-band EQ, Monitor Volume,
    stereo AUX input with level control
  • Chan 1 Direct Out (XLR) with GND lift
  • Integrated pole-cup
  • Metal chassis
  • Panel-mounted POTs/Jacks
  • AC supply/ Battery Charger
  • Lithium Iron Phosphate (LifePO4) battery
  • Up to 4 hours of play time (large capacity battery module available for purchase)
  • Fast Charge time
  • Designed and assembled in USA
